ELECTRICAL CHARACTERISTICS:

1、INDUCTANCE： 100.0KHz at 1.0V (AMBIENT TEMPERATURE  25℃)

L1-2：250.0uH±10%

2、LEAKAGE INDUCTANCE：100.0KHz at 1.0V Short Other Pin

LK8-13：60.0uH  Max            1750 LCR

3、HI-POT TEST：

PRI TO SEC  AC2.0KV/50Hz/5mA/60S

COIL TO CORE  AC1.0KV/50Hz/5mA/60S

5、INSULATION RESISTANCE TEST：

COIL TO COIL AND COIL TO CORE DC500V 100 MΩ  Min
